DTC B1579: Voice Recognition Microphone Disconnected [09/2019 - ]: Wiring Diagram

w/ Sliding Roof

GTY934023Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

w/o Sliding Roof

GTY873845Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
