Components [09/2019 - ]

Fig 1: Front Seatback Heater (For Manual Seat) Replacement Components [09/2019 - ] (1 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

*1	FRONT SEAT CUSHION SHIELD RH	*2	FRONT SEAT INNER CUSHION SHIELD RH
*3	RECLINING ADJUSTER RELEASE HANDLE RH	*4	VERTICAL ADJUSTING HANDLE RH

Fig 2: Front Seatback Heater (For Manual Seat) Replacement Components With Torque Specifications [09/2019 - ] (2 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Callout	Description	Callout	Description
*1	SEPARATE TYPE FRONT SEATBACK ASSEMBLY	*2	SEPARATE TYPE FRONT SEAT CUSHION ASSEMBLY
	Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf)	-	-

Fig 3: Front Seatback Heater (For Manual Seat) Replacement Components [09/2019 - ] (3 Of 4)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

FRONT SEAT HEADREST SUPPORT

SEPARATE TYPE FRONT SEATBACK COVER WITH PAD

Fig 4: Front Seatback Heater (For Manual Seat) Replacement Components [09/2019 - ] (4 Of 4)

*1	FRONT SEATBACK HEATER ASSEMBLY RH	*2	SEPARATE TYPE FRONT SEATBACK COVER
*3	SEPARATE TYPE FRONT SEATBACK PAD	*4	TAG PIN
*5	HOG RING	-	-
•	Non-reusable part	-	-
