Safety Connect System - Diagnostic Codes & Symptom Tests (Except Hybrid)
>>
Safety Connect System
>>
DTC B1537-11: Telephone Sub Antenna Circuit Short to Ground; DTC B1537-13: Telephone Sub Antenna Circuit Open [10/2020 - ]
>>
Wiring Diagram
DTC B1537-11: Telephone Sub Antenna Circuit Short to Ground; DTC B1537-13: Telephone Sub Antenna Circuit Open [10/2020 - ]: Wiring Diagram
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
