DTC B1579: Voice Recognition Microphone Disconnected [04/2018 - 08/2020]: Wiring Diagram

w/ Sliding Roof

GTY873835Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

w/o Sliding Roof

GTY873834Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
