Removal [08/2019 - ]: Procedure

  1. REMOVE LUGGAGE COMPARTMENT DOOR COVER

    Refer to PROCEDURE - Step 1

  2. REMOVE REAR SPOILER SUB-ASSEMBLY
    1. Apply protective tape around the rear spoiler sub-assembly as shown in the illustration.
      GTY907991Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
      Protective Tape
    2. Remove the 2 nuts.
      GTY932780Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    3. except TRD:
      1. Separate the double-sided tape and disengage the 5 clips to remove the rear spoiler sub-assembly.
        GTY919213Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
        Double-sided Tape
    4. for TRD:
      1. Separate the double-sided tape and disengage the 5 clips to remove the rear spoiler sub-assembly.
        GTY907044Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
        Double-sided Tape
