Components [06/2020 - ]
WARNING: This page is about a different variant/trim than selected.
| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | BATTERY HOLE COVER | *2 | DECK BOARD ASSEMBLY |
| *3 | NEGATIVE AUXILIARY BATTERY TERMINAL | *4 | REAR NO. 2 FLOOR BOARD |
| Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | - | - |
| *1 | BATTERY SERVICE HOLE COVER | *2 | SERVICE PLUG GRIP |
| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | CONNECTOR COVER ASSEMBLY | *2 | ENGINE ROOM MAIN WIRE |
| Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | N.m (kgf/cm, ft.lbf): Specified torque |
| Callout | Description | Callout | Description |
|---|---|---|---|
| *1 | FRONT DIFFERENTIAL SUPPORT ASSEMBLY | *2 | REAR SUSPENSION MEMBER SUB-ASSEMBLY |
| *3 | REAR TRACTION MOTOR CABLE | *4 | REAR TRACTION MOTOR FILLER PLUG |
| *5 | REAR TRACTION MOTOR WITH TRANSAXLE ASSEMBLY | *6 | WIRE HARNESS |
| *7 | WIRE HARNESS CLAMP BRACKET | *8 | GASKET |
| *9 | UPPER DIFFERENTIAL MOUNT STOPPER | *10 | LOWER DIFFERENTIAL MOUNT STOPPER |
| *11 | FILLER PLUG | *12 | DRAIN PLUG |
| *13 | MOTOR CABLE TERMINAL CAP | - | - |
| *a | There is no need to remove this unless the rear traction motor filler plug is replaced. | *b | Unnecessary to remove the rear traction motor cable unless inspection or replacement. |
| Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N.m (kgf/cm, ft.lbf) | N.m (kgf/cm, ft.lbf): Specified torque | ||
| * | For use with union nut wrench | • | Non-reusable part |
