Caution / Notice / Hint
WARNING: This page is about a different variant/trim than selected.
The necessary procedures (adjustment, calibration, initialization, or registration) that must be performed after parts are removed and installed, or replaced during battery ECU assembly removal/installation are shown below.
NECESSARY PROCEDURES AFTER PARTS REMOVED/INSTALLED/REPLACED
| Replaced Part or Performed Procedure | Necessary Procedures | Effect/Inoperative Function when Necessary Procedure not Performed | Link |
|---|---|---|---|
| Auxiliary battery terminal is disconnected/reconnected | Perform steering sensor zero point calibration | Lane control system | Refer to INITIALIZATION [11/2018 - 12/2021] |
| Parking support brake system* | |||
| Pre-collision system | |||
| Lighting system (EXT) (w/ AFS) | |||
| Memorize steering angle neutral point | Parking assist monitor system | Refer to INITIALIZATION [11/2018 - 10/2022] | |
| Panoramic view monitor system | Refer to INITIALIZATION [11/2018 - 10/2022] | ||
| Reset back door close position | Power back door system | Refer to INITIALIZATION [11/2018 - 10/2023] | |
| Power back door initialization | Power door lock control system | Refer to INITIALIZATION [11/2018 - ] | |
| Replacement of battery ECU assembly | Current sensor offset learning | DTCs are stored | Refer to PROCEDURE - Step 14 |
*: When performing learning using the Techstream.
WARNING:
- Orange wire harnesses and connectors indicate high-voltage circuits. To prevent electric shock, always follow the procedure described in the appropriate service information
.
Refer to PRECAUTION [06/2020 - ]
- To prevent electric shock, wear insulated gloves when working on wire harnesses and components of the high voltage system.
NOTE:
- After turning the power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work.
Refer to PRECAUTION [11/2018 - ]
- The type of battery ECU assembly to be used varies depending on the vehicle model.
- The type of battery ECU assembly can be confirmed by the color of the label.
*a Black Label - If the wrong type of battery ECU assembly is installed, the power switch cannot be turned on (READY).
- After installing the battery ECU assembly, perform the following to check that the power switch can be turned on (READY).
- Turn the power switch on (READY).
- Turn the power switch off and wait for 30 seconds or more.
- Turn the power switch on (READY) again.
