Section 38 (Engine Control System (Service Information) [A25A-FXS])
>>
Crankshaft Position Sensor
>>
Components [04/2018 - ]
Components [04/2018 - ]
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Crankshaft Position Sensor Replacement Components With Torque Specifications
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout
Description
Callout
Description
*1
COOL AIR INTAKE DUCT SEAL
*2
CRANKSHAFT POSITION SENSOR
*3
INLET AIR CLEANER ASSEMBLY
-
-
N*m (kgf*cm, ft.*lbf): Specified torque
-
-
