Removal [06/2015 - ]: Procedure

  1. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSEMBLY LH

    Refer to REMOVAL [06/2015 - ]

  2. REMOVE REAR FLOOR BOARD SPACER
    1. Remove the rear floor board spacer.
      GTY580018Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  3. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY WITH BRACKET
    1. Remove the 2 nuts.
      GTY580066Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Disengage the clips.
    3. Remove stereo component amplifier assembly.
    4. Disconnect the 2 connectors as shown in the illustration.
      GTY580051Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  4. REMOVE NO. 2 AMPLIFIER BRACKET
    1. Remove the 2 bolts and No. 2 amplifier bracket.
      GTY580052Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  5. REMOVE NO. 1 AMPLIFIER BRACKET
    1. Remove the 2 bolts and No. 1 amplifier bracket.
      GTY580053Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
