Components [12/2013 - ]: Illustration

WARNING: This page is about a different variant/trim than selected.
Fig 1: Vacuum Switching Valve (For ACIS) Replacement Components With Torque Specifications (1 Of 2)
GTY444638Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

-

Callout Description Callout Description
*1 NO. 2 HOSE CLAMP BRACKET *2 OUTER COWL TOP PANEL SUB-ASSEMBLY
N*m (kgf*cm, ft.*lbf): Specified torque - -


Fig 1: Vacuum Switching Valve (For ACIS) Replacement Components With Torque Specifications (2 Of 2)
GTY439162Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 VACUUM SWITCHING VALVE ASSEMBLY (for ACIS) *2 UNION TO VACUUM TUBE HOSE
*3 VACUUM HOSE *4 VACUUM HOSE CLAMP
N*m (kgf*cm, ft.*lbf): Specified torque - -
