Components [06/2017 - ]
WARNING: This page is about a different variant/trim than selected.
| Callout | Description | Callout | Description |
| *1 | FRONT FLOOR COVER LH | *2 | FRONT FLOOR COVER RH |
| N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
| Callout | Description | Callout | Description |
| *1 | NO. 1 ENGINE UNDER COVER | *2 | FRONT WHEEL OPENING EXTENSION PAD LH |
| *3 | FRONT WHEEL OPENING EXTENSION PAD RH | *4 | REAR ENGINE UNDER COVER RH |
| *5 | BODY MOUNTING PLATE | *6 | COOL AIR INTAKE DUCT SEAL |
| N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
Fig 3: Exhaust Manifold And Catalytic Converter Replacement Components With Torque Specifications (3 Of 4)
| Callout | Description | Callout | Description |
| *1 | FRONT EXHAUST PIPE ASSEMBLY | *2 | NO. 1 EXHAUST PIPE SUPPORT BRACKET (for Lower Side) |
| *3 | GASKET | - | - |
| N*m (kgf*cm, ft.*lbf): Specified torque | • | Non-reusable part |
Fig 4: Exhaust Manifold And Catalytic Converter Replacement Components With Torque Specifications (4 Of 4)
| Callout | Description | Callout | Description |
| *1 | EXHAUST MANIFOLD ASSEMBLY RH (TWC: Front Catalyst) | *2 | EXHAUST MANIFOLD ASSEMBLY LH (TWC: Front Catalyst) |
| *3 | NO. 2 EXHAUST MANIFOLD HEAT INSULATOR | *4 | NO. 1 EXHAUST MANIFOLD HEAT INSULATOR |
| *5 | EXHAUST MANIFOLD TO HEAD GASKET (for Bank 1) | *6 | EXHAUST MANIFOLD TO HEAD GASKET (for Bank 2) |
| *7 | AIR FUEL RATIO SENSOR (for Bank 1) | *8 | AIR FUEL RATIO SENSOR (for Bank 2) |
| *9 | NO. 2 MANIFOLD STAY | *10 | V-BANK COVER SUB-ASSEMBLY |
| *11 | STUD BOLT | *12 | ENGINE OIL LEVEL DIPSTICK |
| *13 | ENGINE OIL LEVEL DIPSTICK GUIDE | *14 | ENGINE OIL LEVEL DIPSTICK GUIDE O-RING |
| N*m (kgf*cm, ft.*lbf): Specified torque | * | For use with SST | |
| • | Non-reusable part | - | - |
