Components [06/2017 - ]
WARNING: This page is about a different variant/trim than selected.
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
| *1 |
AIR CLEANER CAP WITH AIR CLEANER HOSE |
*2 |
ENGINE COOLANT TEMPERATURE SENSOR |
| *3 |
VACUUM HOSE |
*4 |
NO. 1 FUEL VAPOR FEED HOSE |
| *5 |
NO. 2 VENTILATION HOSE |
- |
- |
