Components [06/2017 - ]

WARNING: This page is about a different variant/trim than selected.
Fig 1: Park / Neutral Position Switch Replacement Components With Torque Specifications (1 Of 2)
GTY771739Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 BATTERY CLAMP SUB-ASSEMBLY - -
N*m (kgf*cm, ft.*lbf): Specified torque - -
Fig 2: Park / Neutral Position Switch Replacement Components With Torque Specifications (2 Of 2)
GTY763604Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 TRANSMISSION CONTROL CABLE ASSEMBLY *2 TRANSMISSION CONTROL SHAFT LEVER
*3 PARK/NEUTRAL POSITION SWITCH ASSEMBLY *4 WASHER
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) - -
