Components [09/2019 - ]

WARNING: This page is about a different variant/trim than selected.
Fig 1: Fuel Pump ECU Replacement Components With Torque Specifications [09/2019 - ] (1 Of 5)
GTY891363Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*A for Fold Down Seat Type - -
*1 REAR CENTER SEAT OUTER BELT ASSEMBLY *2 REAR SEAT CUSHION ASSEMBLY
*3 REAR SEAT CUSHION LOCK HOOK *4 REAR SEAT INNER BELT ASSEMBLY RH
*5 WASHER - -
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) • Non-reusable part
Fig 2: Fuel Pump ECU Replacement Components With Torque Specifications [09/2019 - ] (2 Of 5)
GTY907925Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*A for Fold Down Seat Type *B w/o Removable Headrest
*1 REAR DOOR OPENING TRIM WEATHERSTRIP LH *2 REAR DOOR OPENING TRIM WEATHERSTRIP RH
*3 REAR SEATBACK ASSEMBLY LH *4 REAR SIDE SEATBACK ASSEMBLY LH
*5 REAR SIDE SEATBACK ASSEMBLY RH - -
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) - -
Fig 3: Fuel Pump ECU Replacement Components With Torque Specifications [09/2019 - ] (3 Of 5)
GTY912916Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*A for Fold Down Seat Type *B w/ Removable Headrest
*1 REAR DOOR OPENING TRIM WEATHERSTRIP LH *2 REAR DOOR OPENING TRIM WEATHERSTRIP RH
*3 REAR SEAT HEADREST ASSEMBLY LH *4 REAR SEATBACK ASSEMBLY LH
*5 REAR SIDE SEATBACK ASSEMBLY LH *6 REAR SIDE SEATBACK ASSEMBLY RH
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) - -
Fig 4: Fuel Pump ECU Replacement Components With Torque Specifications [09/2019 - ] (4 Of 5)
GTY744115Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 PACKAGE TRAY TRIM PANEL ASSEMBLY *2 REAR SEAT OUTER BELT ASSEMBLY LH
*3 REAR SEAT OUTER BELT ASSEMBLY RH *4 REAR SEAT SHOULDER BELT HOLE COVER
*5 INNER ROOF SIDE GARNISH LH *6 INNER ROOF SIDE GARNISH RH
*7 ROOM PARTITION BOARD LH - -
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) - -
Fig 5: Fuel Pump ECU Replacement Components With Torque Specifications [09/2019 - ] (5 Of 5)
GTY744648Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 FUEL PUMP CONTROL ECU *2 FUEL PUMP CONTROL ECU BRACKET
N*m (kgf*cm, ft.*lbf): Specified torque - -
