DTC U1002: Lost Communication with Gateway Module (Sensor Bus); DTC U0235: Lost Communication with Cruise Control Front Distance Range Sensor [08/2015 - ]: Wiring Diagram

Fig 1: Gateway Module (Sensor Bus) Wiring Diagram
GTY590108Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
