Components [11/2016 - ]: Illustration

Fig 1: Seat Heater Control (For Front Side) Replacement Components
GTY731766Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 FRONT SEAT ASSEMBLY *2 SEAT HEATER CONTROL SUB-ASSEMBLY
