Illustration 2

Fig 1: Lighting System Component Location, 02/2014 - 11/2016 (2 Of 4)
GTY430327Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 SHIFT LEVER POSITION SENSOR *2 OUTER REAR VIEW MIRROR ASSEMBLY LH
- DOOR MIRROR FOOT LIGHT LH
*3 OUTER REAR VIEW MIRROR ASSEMBLY RH
- DOOR MIRROR FOOT LIGHT RH		 *4 OUTER MIRROR CONTROL ECU ASSEMBLY LH (w/ Door Mirror Foot Light)
*5 OUTER MIRROR CONTROL ECU ASSEMBLY RH (w/ Door Mirror Foot Light) - -
