Components [02/2014 - ]: Illustration

Fig 1: Combination Meter Replacement Components (1 Of 2)
GTY438130Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 DECK BOARD ASSEMBLY *2 NO. 3 DECK BOARD SUB-ASSEMBLY


Fig 1: Combination Meter Replacement Components (2 Of 2)
GTY431329Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 COMBINATION METER ASSEMBLY *2 COMBINATION METER GLASS
*3 INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY - -
