Components [11/2016 - ]: Illustration

WARNING: This page is about a different car, the 2019 Toyota Highlander, 2018 Toyota Highlander, and 2017 Toyota Highlander. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Backup Boost Converter Replacement Component With Torque Specifications (1 Of 2)
GTY690390Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout Description Callout Description
*1 FRONT BUMPER ENERGY ABSORBER *2 FRONT BUMPER REINFORCEMENT
N*m (kgf*cm, ft.*lbf): Specified torque - -


Fig 1: Backup Boost Converter Replacement Component (2 Of 2)
GTY687805Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 ECO RUN VEHICLE CONVERTER ASSEMBLY *2 NO. 1 CONVERTER CONTROL BRACKET
