SRS Warning Light does not Come ON [08/2013 - 12/2013]: Wiring Diagram

WARNING: This page is about a different variant/trim than selected.
Fig 1: Combination Meter Assembly Wiring Diagram
GTY315446Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
