Air Cooled Oil Cooler: Components: Illustration

WARNING: This page is about a different variant/trim than selected.
Fig 1: Identifying Air Cooled Oil Cooler Replacement Components (1 Of 2)
GTY304535Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002


Fig 1: Identifying Air Cooled Oil Cooler Replacement Components With Torque Specifications (2 Of 2)
GTY299983Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
