DTC B1655/37: Driver Side Seat Belt Buckle Switch Circuit Malfunction: Wiring Diagram

Fig 1: Identifying Driver Side Seat Belt Buckle Switch - Wiring Diagram
GTY210084Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
