Transmission Control Switch Circuit: Wiring Diagram

WARNING: This page is about a different car, the 2010 Toyota Camry. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: CAN Communication - Wiring Diagram
GTY185036Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
