Corolla XLE
>>
Repair and Diagnosis
>>
Electrical
>>
Motors, Switches, Relays
>>
OEM Overall Electrical Wiring Diagram
>>
Overall Electrical Wiring Diagram
>>
Back-Up Light (Except TMC Made), Stop Light (Except TMC Made)
Back-Up Light (Except TMC Made), Stop Light (Except TMC Made)
Fig 1: Back-Up Light And Stop Light - Electrical Wiring Diagram - Except TMC Made
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
