Purge Valve: Components

WARNING: This page is about a different variant/trim than selected.
Fig 1: Purge Valve Replacement Components With Torque Specifications (1 Of 2)
G06115094Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Purge Valve Replacement Components With Torque Specifications (2 Of 2)
G06115095Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
