OEM Junction Block, Ecu & Fuse/Relay Locations (Except Hybrid)
>>
Junction Block Fuse, Relay & Circuit Identification
>>
Junction Block No. 4)
Junction Block No. 4)
Instrument Panel Brace Center
(See
Figure
Fig 1: J/B No. 4 Connector Locations - Instrument Panel Brace Center
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
