Home >> Toyota >> 2008 >> Highlander Base, FWD >> Repair and Diagnosis >> Body & Frame >> Exterior Body Panels >> (Door / Hatch) (Except Hybrid) >> Power Back Door Closer Switch >> Components

Power Back Door Closer Switch: Components

Fig 1: Power Back Door Closer Switch Replacement Components With Torque Specifications

G05422324

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
