DTC C1776/76: Speed Sensor Circuit: Wiring Diagram

WARNING: This page is about a different car, the 2007 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Speed Sensor Circuit Wiring Diagram (1 Of 2)
G04437453Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Speed Sensor Circuit Wiring Diagram (2 Of 2)
G04437454Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
