DTC P2759: Torque Converter Clutch Pressure Control Solenoid Control Circuit Electrical (Shift Solenoid Valve SLU): Wiring Diagram

WARNING: This page is about a different car, the 2006 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Torque Converter Clutch Pressure Control Solenoid Control Circuit - Wiring Diagram
G04436514Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
