DTC C1244/44: Open or Short in Deceleration Sensor Circuit: Wiring Diagram

WARNING: This page is about a different car, the 2006 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Open Or Short In Deceleration Sensor Wiring Diagram
G04440354Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
