RADIO ANTENNA CORD (for Sedan): Components

WARNING: This page is about a different car, the 2008 Toyota Yaris. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Roof Headlining Replacement Components With Torque Specifications - Sedan (1 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Roof Headlining Replacement Components With Torque Specifications - Sedan (2 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: Identifying Roof Headlining Components - Sedan (3 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: Roof Headlining Replacement Components With Torque Specifications - Sedan (4 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 5: Roof Headlining Replacement Components With Torque Specifications - Sedan (5 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 6: Identifying Roof Headlining Components - Sedan (6 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 7: Identifying Roof Headlining Components - Sedan (7 Of 11)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 8: Identifying Roof Headlining Components - Sedan (8 Of 11)

Fig 9: Roof Headlining Replacement Components With Torque Specifications - Sedan (9 Of 11)

Fig 10: Identifying Roof Headlining Components - Sedan (10 Of 11)

Fig 11: Identifying Roof Headlining Components - Sedan (11 Of 11)
