REAR COMBINATION LIGHT ASSEMBLY (for Hatchback): Components

WARNING: This page is about a different car, the 2008 Toyota Yaris. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Rear Combination Light Connector (Hatchback)
G04832851Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
