Front Door: Adjustment

WARNING: This page is about a different car, the 2008 Toyota RAV4. However, it is still accessible from the selected car via links, so may be relevant.

HINT:

Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
Centering bolts are used to mount the door hinge to the vehicle body and door. The door cannot be adjusted with the centering bolts on. Substitute the centering bolts with standard bolts (with washers) when making adjustments.
A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Fig 1: Identifying Centering Bolts With Standard Bolts (With Washers)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
ADJUST FRONT DOOR PANEL SUB-ASSEMBLY LH
1. Using SST, loosen the body's hinge bolts and adjust the door's position.
  SST 09812-00010

  Fig 2: Loosening Body's Hinge Bolts And Adjusting Door's Position
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Tighten the body's hinge bolts after the adjustment.
  Torque: 26 N*m (265 kgf*cm, 19 ft.*lbf)
3. Loosen the door's hinge bolts and adjust the door's position.
4. Tighten the door's hinge bolts after the adjustment.
  Torque: 26 N*m (265 kgf*cm, 19 ft.*lbf)
5. Using a T40 "Torx" socket, adjust the striker position by slightly loosening the striker mounting screws and then hitting the striker with a plastic-faced hammer.

  Fig 4: Tightening Striker Mounting Screws
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
6. Using a T40 "Torx" socket, tighten the striker mounting screws after the adjustment.
  Torque: 23 N*m (235 kgf*cm, 17 ft.*lbf)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
