Heated Oxygen Sensor: Removal

WARNING: This page is about a different car, the 2007 Toyota RAV4. However, it is still accessible from the selected car via links, so may be relevant.

DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
REMOVE HEATED OXYGEN SENSOR (for Sensor 2)
1. Bank 1 Sensor 2:
  Remove the rear console box (see appropriate step(s) under LOWER INSTRUMENT PANEL , also refer to Figure).
2. Disconnect the sensor connector.
3. Using SST, remove the sensor from the exhaust pipe.
  SST 09224-00010

  Fig 1: Removing Sensor(s) No. 2 From Exhaust Pipe
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
