Automatic Glare-Resistant EC Mirror and Compass, Fuel Lid Opener, Remote Control Mirror (w/o Driving Position Memory)

Fig 1: Fuel Lid Opener Electrical Wiring Diagram
G07616722Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
