Relay Block No. 1 Lower Finish Panel

Refer to Figure

Fig 1: R/B No. 1 Relay Locations
G08782283Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
R/B NO. 1 RELAY IDENTIFICATION

RELAY DESCRIPTION
Deicer Relay
Seat Heater Relay
