DTC C0278/11 Open Circuit In Abs Solenoid Relay Circuit: DTC C0279/12 Short Circuit In Abs Solenoid Relay Circuit: Wiring Diagram

Fig 1: Identifying Open/Short Circuit In ABS Solenoid Relay Circuit Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
