Multi-Information Display Screen Does Not Change When Steering Pad Switch Is Operated: Wiring Diagram

Fig 1: Wiring Diagram - Multi-Information Display

G04391060

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
