Malfunction In Average Fuel Consumption/Instantaneous Fuel Consumption Display: Wiring Diagram

Fig 1: Wiring Diagram - Fuel Consumption Display

G04391041

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
