Front Brake Caliper: Removal

Remove the wheel and temporarily fasten the disc with the hub nuts.

Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)

Fig 1: Removing Front Wheel

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Remove the union bolt and gasket from the caliper, then disconnect the flexible hose from the caliper.

Torque: 30 N.m (310 kgf.cm, 22 ft.lbf)

HINT:

• At the time of installation, install the flexible hose lock securely in the lock hole in the caliper.
• Use a container to catch the brake fluid as it drains out.

1. Hold the sliding pin and remove the 2 installation bolts.

   Torque: 34 N.m (350 kgf.cm, 25 ft.lbf)

2. Remove the caliper from the torque plate.
