Circuit Description
The brake actuator receives signals from the yaw rate sensor via the CAN communication system.
The yaw rate sensor has a built-in deceleration sensor.
If there is trouble in the bus lines between the yaw rate sensor and CAN communication system, the DTC U0123/62 (yaw rate sensor communication trouble) and U0124/95 (deceleration sensor communication trouble) are output.
