Circuit Description
1MZ, 3MZ
The circuit is used to send TRAC & VSC control information from the skid control ECU to the ECM (TRC+, TRC-), and engine control information from the ECM to the skid control ECU (ENG+, ENG-).
2AZ
The ECM signal circuit is used for the CAN communication system.
