Circuit Description
The skid control ECU measures the speed of each wheel by receiving signals from the speed sensor. These signals are used for recognizing if all 4 wheels are operating properly. Therefore, all wheel signals must be equal.
The skid control ECU measures the speed of each wheel by receiving signals from the speed sensor. These signals are used for recognizing if all 4 wheels are operating properly. Therefore, all wheel signals must be equal.
