Removal and Installation: Removal

WARNING: This page is about a different car, the 2013 Nissan Armada. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative battery terminal. Refer to "REMOVAL AND INSTALLATION ".
  2. Slide the front seat (RH) forward.
  3. Remove the Bluetooth control unit kick shield screws and the Bluetooth control unit kick shield.
  4. Remove the Bluetooth control unit (1).
    1. Remove the Bluetooth control unit screws (A)
    2. Disconnect the harness connectors from the Bluetooth control unit.
      Fig 1: Identifying Bluetooth Control Unit With Mounting Screws
      G08698370Courtesy of NISSAN NORTH AMERICA, INC.
