Removal and Installation - Bucket Seat (LH/RH): Removal

WARNING: This page is about a different car, the 2013 Nissan Armada. However, it is still accessible from the selected car via links, so may be relevant.
  1. Tilt seat to the forward position.
  2. Remove two nuts (A), two bolts (B) and the seat assembly.
    Fig 1: Identifying Seat Assembly With Mounting Bolts And Nuts
    G08694267Courtesy of NISSAN NORTH AMERICA, INC.
