Component Inspection

WARNING: This page is about a different car, the 2013 Nissan Armada. However, it is still accessible from the selected car via links, so may be relevant.

CHECK WASHER FLUID LEVEL SWITCH

Check continuity between washer fluid level switch terminals 1 and 2.

Terminal	Washer fluid level	Continuity
1 - 2	Low	Yes
1 - 2	Other	No

Fig 1: Checking Continuity Between Washer Fluid Level Switch Terminals 1 And 2

Courtesy of NISSAN NORTH AMERICA, INC.

Is the inspection result normal?

YES: Inspection End.

NO: Replace washer fluid level switch.
