DTC P0300: Random/Multiple Cylinder Misfire Detected, DTC P0301: Cylinder 1 Misfire Detected, DTC P0302: Cylinder 2 Misfire Detected, DTC P0303: Cylinder 3 Misfire Detected, DTC P0304: Cylinder 4 Misfire Detected: Wiring Diagram

WARNING: This page is about a different car, the 2004 Toyota Corolla. However, it is still accessible from the selected car via links, so may be relevant.

Refer to DTC P0351  for the wiring diagram of the ignition system.

Fig 1: Camshaft And Crankshaft Position Sensor Wiring Diagram
G03946617Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
