Circuit Description
WARNING: This page is about a different car, the 2005 Toyota 4Runner. However, it is still accessible from the selected car via links, so may be relevant.
Upon receiving the DAC or HAC operating signal from the skid control ECU, the relay contact turns on and the stop light comes on.
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
