Shift Solenoid SLT
WARNING: This page is about a different car, the 2002 Toyota ECHO, 2002 Toyota Celica, 2001 Toyota ECHO, and 2001 Toyota Celica. However, it is still accessible from the selected car via links, so may be relevant.
ECM controls line pressure by sending a predetermined duty ratio to shift solenoid SLT, modulating line pressure and generating throttle pressure. Shift solenoid SLT is used to precisely and minutely modulate and generate line pressure according to accelerator pedal effort, or engine power output detected. Shift solenoid SLT is located on transaxle valve body. See Fig 1.
