Side AIR Bag Module
WARNING: This page is about a different car, the 2002 Toyota Camry. However, it is still accessible from the selected car via links, so may be relevant.
- Before proceeding, see AIR BAG SAFETY PRECAUTIONS . Disable air bag system. See DISABLING SYSTEM under DISABLING & ACTIVATING AIR BAG SYSTEM. Ensure seat back is not loose. If components are loose, remove and deploy air bag(s) using OFF-VEHICLE DEPLOYMENT procedure. Test Deployment Tool (09082-00700). See TESTING DEPLOYMENT TOOL . Disconnect appropriate side air bag connector, located under front seat.
- Connect deployment tool, using Deployment Tool Sub-Harness Adapter (09082-00750) to side air bag connector. Position deployment tool at least 33 feet from front of vehicle. Close all doors and windows of vehicle. Connect deployment tool Red clip to positive battery terminal and Black clip to negative battery terminal.
- Ensure no one is inside vehicle or within 33 feet of vehicle. Press activation switch to deploy air bag. Because of heat, DO NOT touch air bag for at least 30 minutes after deployment. Scrap vehicle with air bag(s) still installed.
